Description
True Interactivity for Bringing People Together
With differentiated cutting-edge touch technology, the TR3BF Series supports multi-touch & writing functions providing accurate drawing and authentic touch quality. In addition, the Air Class and web browsers support multi-directional communication and interactive learning, which will help you achieve the successful business.
GENUINE TOUCH & WRITING EXPERIENCE
Multi Touch & Writing
The TR3BF Series can simultaneously use up to 20 points of multitouch and 10 points of writing, as well as 2 types of stylus pens. This function offers a lifelike board writing experience and makes collaboration much easier.
Technical data
Panel
| Screen Size | 65″, 75″, 86″ |
|---|---|
| Panel Technology | IPS |
| Aspect Ratio |
16 : 9 |
| Native Resolution |
3840 x 2160 (UHD) |
| Brightness(Typ., cd/m², w/ Protection Glass) |
330 |
| Contrast Ratio |
65″- 1200:1, 75″, 86″- 1,100:1 |
| Viewing Angle (H x V) |
178 x 178 |
| Response Time |
9 ms (G do G) |
| Life Time (Typ.) | 30,000 Hrs (Min.) |
| Operation Hours |
16Hr |
| Orientation |
Landscape |
Connectivity
| (Input) Video / Audio | HDMI (3), RGB / Audio In |
|---|---|
| (Input) External Control | RS232C In, RJ45 |
| (Input) USB | USB 2.0 (3, Front : 2ea, Bottom side: 1ea Only for software update), USB 3.0 (3), Touch Out(USB2.0,B Type) (2) |
| (Output) Video / Audio | HDMI (1), Optical Output / Audio Out |
Mechanical Specification
| Bezel Color | Black |
|---|---|
| Bezel Width(Off Bezel) | Top/Right/Left:17.7mm, Bottom:45.7mm |
| Monitor Dimension (W × H × D) |
65″- 1488×897×86 mm, 75″- 1,709×1,020×86mm, 86″- 1,957×1,160×86mm |
| Weight (Head) |
65″- 40 kg, 75″- 53kg, 86″- 67kg |
| Carton Dimensions(W x H x D) with pallet |
65″- 1700×1175×250 mm, 75″- 1,950×1,266×285mm, 86″- 2,230×1,499×285mm |
| Packed Weight |
65″- 67,6 kg, 75″- 85kg, 86″- 109kg |
|
Handle |
Yes |
| VESA™ Standard Mount Interface |
65″- 600 x 400, 75″- 800 x 400, 86″- 800 x 600 |
Environment Conditions
| Operation Temperature |
0 °C to 40 °C |
|---|---|
| Operation Humidity | 10 % to 80 % |
Power
| Power Supply |
100–240 V~, 50/60 Hz |
|---|---|
| Power Type | Built-In Power |
| Power Consumption (Typ. / Max.) |
65″- 145 W / 275 W, 75″- 175 W / 294 W, 86″- 365 W / 419 W |
Sound
|
Speaker |
Built in 24W (12W + 12W) |
|---|
Standard (Certification)
|
Safety |
CB / NRTL |
|---|---|
|
EMC |
Klasa FCC A / CE |
|
ErP / Energy Star |
Yes (EU Only) / No |
Media Player Compatibility
| OPS type compatible | Yes |
|---|
Accessory
|
Basic |
Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Control |
|---|
Touch Specifications
| Touch type |
IR |
|---|---|
| Available object size for touch |
Ø3 mm ↑ |
| Response Time |
60 ms ↓ (Android) / 100 ms ↓ (Windows) |
| Accuracy |
1,5 mm |
|
Interface |
USB 2.0 |
| Protection Glass Thickness |
4 T (antyodblaskowa) |
| Protection Glass Transmission |
87% |
| Operating System Support |
Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch) |
| Multi touch point |
Max 20 Points / Max 10 Writing |
